Overview
Solid, focused and precisely positionable.
The high-end sound of a condenser microphone is combined with the features of professional stage equipment to make the e 908 a small, highly flexible marvel. With an open and high-definition character, it creates surprisingly forceful sounds. It transmits the attack in a very clear and defined manner while structure-borne noise is reliably suppressed. Thanks to its shock-mounted head, gooseneck and special clips, the e 908 can be quickly attached and precisely oriented to the sound source. Despite its delicate form, the microphone is ruggedly constructed and easily takes even hard hits. The e 908 is available in four models:
	- e 908 D: for drums and percussion

	- e 908 B: for wind instruments, congas, and drums with free-floating suspension system

	- e 908 B ew: for wireless miking of saxophones using an evolution wireless instrument transmitter

For more information please navigate to the section "variants".
Features
	-

Condenser microphone

	-

High-end sound and precise definition

	-

Simple mounting thanks to practical clips

	-

Precise orientation with gooseneck microphone boom

	-

Protection against impact and handling noise

	-

Intelligent MZA 900 P phantom powering adapter (only B and D versions)

	-

Can be operated with an evolution wireless instrument transmitter

Technical Data


			|   |




			| Equivalent noise level |
			35 dB(A) |
			500203 |


			| 500205 |


			| 30 dB(A) |
			500204 |


			| 39 dB (A) |
			500632 |


			| Dimensions |
			Ø 47 x 193 mm |
			  |


			| Connector |
			e 908 B & D = XLR-3; e908 B ew & T ew = 3,5mm mini jack |
			  |


			| Transducer principle (Microphone) |
			pre-polarised condenser microphone |
			  |


			| Frequency response |
			40 - 20000 Hz |
			  |


			| Weight |
			ca. 140 g |
			  |


			| Pick-up pattern |
			cardioid |
			  |


			| Sensitivity in free field, no load (1kHz) |
			4 mV/Pa, 0,56mV/Pa (e 908T-ew) |
			  |


			| Nominal impedance |
			100 Ohm (e908B & e908D) |
			  |


			| Min. terminating impedance |
			2000 Ohm (e908B & e908D) |
			  |


			| Phantom powering |
			12 - 48 V / 3 mA (e908B & e908D) |
			  |


			| Max. Sound pressure level (active) |
			e908B-ew = 30 dB(A); e908B & e908D = 35 dB(A), e908T-ew = 39 dB (A) (equi) / 147 dB (max) |
