| Performance |
| Frequency Range (-10 dB) |
35 Hz -125 Hz (variable LPF) |
| Maximum Peak SPL at 1 m |
137 dB |
| Electronics and Connectors |
| Nominal Amplifier Power (continuous) |
1600 W |
| Nominal Amplifier Power (peak) |
3200 W |
| Input Type |
Balanced |
| Input Impeadance |
20 kohms |
| Input Sensitivity |
1.95 V (+8 dBu) |
| Audio Signal Input Connector |
2 x Female XLR |
| Audio Signal Loop Thru Connector |
2 x Male XLR |
| AC Input Connector |
powerCON NAC3MPA |
| AC Output Connector |
powerCON NAC3MPB |
| Operating Range |
180-250 VAC |
| Current Draw 230 V |
1.8 A |
| Enclosure |
| Enclosure Construction |
Birch Plywood |
| Enclosure Geometry |
Rectangular |
| Rigging |
M10 Rigging Points |
| Finish |
ISO-flex Paint |
| Color |
Black |
| Dimensions ( H x W x D ) |
780 x 695 x 570 mm
30,7 x 27,4 x 22,4 in |
| Net Weight |
57,0 kg ( 125,7 lb ) |
| Components |
| LF Driver |
18LX |
| Shipping |
| Carton Dimensions ( H x W x D ) |
875 x 740 x 620 mm
34,5 x 29,1 x 24,4 in |
| Shipping Weight |
61,5 kg ( 135,6 lb ) |
